JLG 70H Parts Manual User Manual
Page 307
3120290
4-9
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
FIGURE 4-2. LOW MOUNT PLATFORM AND FOOTSWITCH INSTALLATION
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
LOW MOUNT PLATFORM AND FOOTSWITCH
INSTALLATION
Ref.
0239341
ROTATOR AND SUPPORT INSTALLATION -
MODELS 60H AND 70H (DOMESTIC/STANDARD)
Ref.
8
0251769
ROTATOR AND SUPPORT INSTALLATION -
MODELS 60H AND 70H (CSA/2:1 STABILITY)
Ref.
5
0239342
ROTATOR AND SUPPORT INSTALLATION - MODEL
60H+6 (DOMESTIC/STANDARD)
Ref.
G
0251770
ROTATOR AND SUPPORT INSTALLATION - MODEL
60H+6 (CSA/2:1 STABILITY)
Ref.
5
1
Not Used
2
Pivot Weldment Options:
1
60H/70H
1
0236741
Pivot Weldment
1
0961024
Bushing, Bronze
2
60H+6
2
Pivot Weldment Options:
1
0237975
Pivot (Prior to March 1991) (Not Shown)
0251512
Pivot (March 1991 to Present) (Not Shown)
0961185
Bushing, Bronze
2
3
Not Used
4
1120299
Cap
1
5
Shaft Options:
1
4842046
Shaft (Domestic/Standard)
Use 4842046
Shaft (CSA/2:1 Stability) (was p/n 4040218)
6
0235238
Rotator Assembly (See Items 101-126 for
Breakdown)
1
7
Mount Options:
1
60H/70H
1
0901525
Mount (Prior to July 1990)
0901721
Mount (July 1990 to S/N 34256)
0902414
Mount (S/N 34256 to Present)
0901524
60H+6
1
8
3340454
Pad, Brake
2
9
2880404
Key
1
10
4160026
Washer, Belleville
8
11
4752000
Flatwasher 5/8”
1
12
0652014
Bolt 5/8”-18NF x 1 3/4”
1
13
0641836
Bolt 1/2”-13NC x 4 1/2”
1
14
4751800
Flatwasher 1/2”
1
15
3311805
Locknut 1/2”-13NC
1
16
Nut 3/8”-16NC Options:
1
3311601
60H/70H
Not Required
60H+6
17
Bolt 3/8”-16NC x 1” Options:
1
0641608
60H/70H
Not Required
60H+6
