SECTION 1 FRAME
FIGURE 1-17. VALVES INSTALLATION (FRAME MOUNTED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
VALVES INSTALLATION (FRAME MOUNTED)
Ref.
0236404
LOCKOUT VALVE INSTALLATION (OSCILLATING
AXLE MACHINES BUILT PRIOR TO MAY 1992)
Ref.
C
1
1100037
Cam Assembly
1
2
0641612
Bolt 3/8” - 16NC
2
3
Not Used
4
4070570
Shim (1/32”)
A/R
4070571
Shim (1/16”)
A/R
4070572
Shim (1/8”)
A/R
5
4640485
Valve, Axle Lockout (See Figure 1-18 for Breakdown)
1
6
0641634
Bolt 3/8”-16NC x 4 1/4”
2
7
4751600
Flatwasher 3/8”
2
8
4761600
Lockwasher 3/8”
4
9
3311601
Nut 3/8”-16NC
2
0252386
LOCKOUT VALVE INSTALLATION (OSCILLATING
AXLE MACHINES BUILT MAY 1992 TO PRESENT)
Ref.
-
51
4640668
Axle Lockout Valve Assembly
1
7012516
Repair Kit
1
52
0901806
Bracket, Mounting
1
53
4751500
Flatwasher 5/16”
2
54
4761500
Lockwasher 5/16”
2
55
3311501
Nut 5/16”-18NC
2
56
3931016
Capscrew, Socket Head #10-24NC x 1”
4
57
4751000
Flatwasher #10
8
58
4761000
Lockwasher #10
4
59
3311001
Nut #10-24NC
4
60
0641612
Bolt 3/8”-16NC x 1 1/2”
2
61
4761600
Lockwasher 38”
2
62
1100037
Cam, Lockout
1
63
4070570
Shim (1/32”)
A/R
4070571
Shim (1/16”)
A/R
4070572
Shim (1/8”)
A/R
0236842
2 WHEEL/4 WHEEL DRIVE VALVES INSTALLAITON
(4WD MACHINES BUILT PRIOR TO MAY 1992)
Ref.
E
101
4640471
Valve
1
7004359
Seal Kit
1
7010656
Solenoid Cartridge Assembly (Includes Coil)
1
102
0641524
Bolt 5/16” - 18NC x 3”
2
103
4751600
Flatwasher 3/8”
4
104
4761600
Lockwasher 3/8”
4
105
3311501
Nut 5/16” - 18NC
4
