5-32 3120290
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
1681574
TELESCOPE CYLINDER ASSEMBLY (PRIOR TO
DECEMBER 1986) (VARIABLE PARTS)
Ref. E
51 3480092 Piston 1
52 Kit Ring, Lock 2
53 Kit Seal 2
— — — — — — — — — —
2900368
Seal Kit - 1681574 Cylinder (Includes Items 10, 14,
15, 18, 29, 52 and 53)
1681813
TELESCOPE CYLINDER ASSEMBLY (DECEMBER
1986 TO PRESENT) (VARIABLE PARTS)
Ref. E
61 3480054 Piston 1
62 Kit Ring, Wear 2
63 Kit Seal 1
— — — — — — — — — —
2901139
Seal Kit - 1681813 Cylinder (Includes Items 10, 14,
15, 18, 29, 62 and 63)
1
FIGURE 5-12. TELESCOPE CYLINDER ASSEMBLIES (MODEL 70H) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
