JLG 70H Parts Manual - Manual (Page 114)

2-36 3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
31 7009325 Retainer 2
32 Spool (Not Sold Separately) 1
33 7006757 Seat 2
34 Kit Ring, Back-Up 2
35 Kit O-Ring 2
36 7006732 Servo Stem Assembly 2
37 7006737 Poppet 2
38 7009321 Retainer (13/16”-2.1cm Length) (Design A) 1
7009363 Retainer (1 3/16”-3cm Length) (Design B) 1
Not Required Retainer (Design C)
Kit O-Ring 1
39 7006752 Retainer 2
40 Kit Ring, Back-Up 2
41 Kit O-Ring 2
42 7006773 Spring 2
43 7006756 Poppet 2
44 7006771 Plug, Torque 1
45 Kit O-Ring 1
46 7006761 Ball (Design A - All Sections Except Swing) 2
7006761 Ball (Design A - Swing Section) 1
7006761 Ball (Design B - All Sections) 2
7009369 Poppet (Design C - All Sections) 2
7009368 Spring (Design C - All Sections) 1
47 7006777 Pin, Solid (Design A - Swing Section Only) 1
Not Required Pin, Solid (Design B and Design C)
48 7006780 Cover End 1
49 7006778 Plug, Torque 1
50 Kit O-Ring 1
51 7009329 Rod, Tie 3
52 7006782 Nut 6
— — — — — — — — — —
7009330
Seal Kit (Includes Items 4,5,6,12,16,27,34,35,
38,40,41,45, 50 and Servo Stem O-Rings)
4
7009395 Seal Kit - Valve Face (Includes Items 4,5 and 6) 5
FIGURE 2-8. VICKERS PROPORTIONAL CONTROL VALVE ASSEMBLY (PRIOR TO OCTOBER 1994)
(CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
