JLG 70H Parts Manual - Manual (Page 29)

3120290 1-21
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
TIRE AND WHEEL ASSEMBLIES Ref.
401 Pneumatic 14” Tire Options: 4
0236817 2WD Front
0236818 2WD Right Rear
0236819 2WD Left Rear
4520024 Tire Only - Front
4520025 Tire Only - Rear
4520171 Tire Only - Front & Rear
See Note Foam-Filled 14” Tire Options: 4
0236625 2WD Front
0236627 2WD Right Rear
0236626 2WD Left Rear
Note: Assemblies may require ballast/foam filling
to manufacture’s specifications prior to installing
on a machine. Refer to Operation & Safety or Ser-
vice & Maintenance Manuals. Purchase individual
tire and/or rim only able to foam fill tire & wheel
assembly, otherwise, purchase complete assem-
bly.
Pneumatic 15” Tire Options: 4
0234666 2WD/2WS Front
0234666 2WD/4WS Front
0234667 2WD/2WS Right Rear
0234668 2WD/2WS Left Rear
0234666 2WD/4WS Rear
0252752 4WD/2WS Right Front and Rear
0271615 4WD/2WS Right Front and Rear
0252752 4WD/4WS Right Front and Rear
0271615 4WD/4WS Right Front and Rear
0252753 4WD/2WS Left Front and Rear
0271614 4WD/2WS Left Front and Rear
0252753 4WD/4WS Left Front and Rear
0271614 4WD/4WS Left Front and Rear
4520009 Firestone 15 x 19.5 Tire Only - 2WD Front
4520142 Denman 15 x 19.5 Tire Only - 2WD/2WS Rear
4520200 Galaxy 15 x 19.5 Tire Only - 2WD/2WS Rear
4520258 OTR 15 x 19.5 Tire Only - 2WD/2WS Rear
4520007 Firestone 15 x 19.5 Tire Only - 2WD/4WS Rear
4520142 Denman 15 x 19.5 Tire Only - 4WD All
4520258 OTR 15 x 19.5 Tire Only - 4WD All
See Note Foam-Filled 15” Tire Options: 4
0236625 2WD/2WS Front
0236625 2WD/4WS Front
0234745 2WD/2WS Left Rear
0234746 2WD/2WS Right Rear
0236625 2WD/4WS Rear
0234745 2WD/2WS Left Front and Rear
0234745 4WD/4WS Left Front and Rear
0234746 4WD/2WS Right Front and Rear
FIGURE 1-4. TIRE AND WHEEL DRIVE INSTALLATIONS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
