JLG 70H Parts Manual User Manual
Page 304
4-6
3120290
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
210
2440044
Gear, Worm
1
211
4740256
Washer, Thrust
2
212
0440135
Bearing, Sleeve
1
213
1760068
Disc, Brake
1
214
Not Used
215
3931010
Bolt, Socket Head #10-24NC x 5/8”
5
216
3441228
Rollpin 3/8” x 1 3/4”
2
217
3931620
Bolt, Socket Head 3/8”-16NC x 1 1/4”
2
218
4761600
Lockwasher 3/8”
6
219
3931612
Bolt, Socket Head 3/8”-16NC x 3/4”
4
220
4070585
Shim .010
A/R
221
4070586
Shim .005
A/R
222
4070587
Shim .002
A/R
223
0100019
Loctite #271 (Not Shown)
A/R
224
0100021
Primer (Not Shown)
A/R
225
2160001
Fitting, Grease - 90°
1
226
3020025
Grease (Not Shown)
A/R
PLATFORM WELDMENTS
Ref.
Note: Replacement Decals Must Be Ordered Sep-
arately - See Section 8.
Ref.
301
Standard Platform Options:
1
3’ x 4’ (91.5cm x 123cm):
60H/70H:
3510138
Platform (Prior to July 1993)
3510438
Platform (July 1993 to Present)
60H+6:
3510439
Platform
3’ x 5’ (91.5cm x 152.5cm):
60H/70H:
3510141
Platform with PQ Controllers (Prior to
September 1990)
3510150
Platform with OEM Controllers (Prior to
September 1990)
3510268
Platform (September 1990 to Present)
3510234
Platform with Welded-on Bumper
3510268
Platform with Chain-Attached Bumper
3510512
Platform with Mesh to Top Rail
60H+6:
3510271
Platform
3510319
Platform with Welded-on Bumper
3510271
Platform with Chain Attached Bumper
FIGURE 4-1. STANDARD PLATFORM AND FOOTSWITCH INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
