3120290 1-61
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
202 (cont’d) 4640260
Machines Built to Installations p/n 0238014,
0251823 & 0252577
1
Consult Factory Cartridge (Vickers/Modular Control Version) 1
7009739 Seal Kit (Vickers/Modular Control Version) 1
7007321 Cartridge (Fluid Control Version) 1
No Longer
Available
Seal Kit (Fluid Control Version) (was p/n
7007323)
1
4640852
Machines Built to Installations p/n 0252576 &
0254394
1
Note: When replacing flow divider on machines
built May 1992 to August 1993 use P/N 4640852
instead P/N 4640260 (as equipped).
4640841 Cartridge 1
203 2220377 Fitting, Straight 1
204 2220844 Fitting, Adapter 1
205 3311501 Nut 5/16”-18NC A/R
206 4751500 Flatwasher 5/16” A/R
207 0641524 Bolt 5/16”-18NC x 3” A/R
208 4640671
Flow Divider Assembly (WD Machines Built May
1992 to Present Only)
1
7010510 Cartridge (Vickers/Modular Controls Version) 1
7009739 Seal Kit (Vickers/Modular Controls Version) 1
Use 70003445
Cartridge (Fluid Controls Version) (was p/n
7007322)
1
No Longer
Available
Seal Kit (Fluid Controls Version) (was p/n
7007323)
1
0252552/
0252553
CONTROL VALVES INSTALLATION - 4WS OPTION
(WITHOUT PROP TELE)
Ref. C/C
0252186/
0253187
CONTROL VALVES INSTALLATION - 4WS OPTION
(WITH PROP TELE)
Ref. B/B
301 4640684
Control Valve Assembly (See Figure 1-19 for Break-
down)
1
302 4300038 Stud (Welded on Part) 4
303 3311501 Nut 5/16”-18NC 4
304 4751500 Flatwasher 5/16” 4
305 4761500 Lockwasher 5/16” 4
FIGURE 1-17. VALVES INSTALLATION (FRAME MOUNTED) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
