SECTION 6 HYDRAULICS
FIGURE 6-14. HYDRAULIC DIAGRAM - TELESCOPE
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
HYDRAULIC DIAGRAM - TELESCOPE
Ref.
2791257
HYDRAULIC DIAGRAM - TELESCOPE (STANDARD
NON-PROPORTIONAL CONTROLS)
Ref.
F
1
2751114
Hose
2
2
2220343
Fitting, Straight
2
3
2220372
Fitting, Straight
1
4
2220606
Fitting, Tee
2
5
Not Used
6
2220371
Fitting, Straight
1
7
2750921
Hose
2
8
0100020
Sealant, Thread (Not Shown)
A/R
9
2180479
Fitting, Modified
1
10
2180486
Orifice (1/8”)
1
11
Not Used
12
0100011
Loctite (Not Shown)
A/R
2791254
HYDRAULIC DIAGRAM - TELESCOPE (STANDARD
PROPORTIONAL CONTROLS)
Ref.
D
101
2751114
Hose
2
102
2220343
Fitting, Straight
2
103
2220577
Fitting, Straight
1
104
Not Used
105
Not Used
106
Not Used
107
Not Used
108
0100020
Sealant, Thread (Not Shown)
A/R
109
2220635
Fitting, Tee
1
110
2180780
Orifice (5/32”)
1
111
2180384
Fitting, Modified
1
2792051
HYDRAULIC DIAGRAM - TELESCOPE (HYDRAULIC
CONTROLS)
Ref.
-
201
2751114
Hose
2
202
2220343
Fitting, Straight
2
203
2220635
Fitting, Tee
1
204
0100020
Sealant, Thread (Not Shown)
A/R
