JLG 70H Parts Manual User Manual
Page 350
5-4
3120290
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
52
Rod Assembly Options:
1
1681450
2WD Machines Built to May 1992
1681447
4WD Machines Built to May 1992
1682569
Machines Built May 1992 to Present
53
Bushing, Bronze Options:
1
Not Required
2WD Machines Built to May 1992
Not Required
4WD Machines Built to May 1992
0960524
Machines Built May 1992 to Present
54
Spacer Options:
1
4562935
2WD Machines Built to May 1992
4562935
4WD Machines Built to May 1992
4565550
Machines Built May 1992 to Present
55
Fitting, Grease Options:
1
2160002
2WD Machines Built to May 1992
2160002
4WD Machines Built to May 1992
Not Required
Machines Built May 1992 to Present
56
Bleeder Options:
3
4640273
2WD Machines Built to May 1992
4640273
4WD Machines Built to May 1992
Not Required
Machines Built May 1992 to Present
Note: Items 57 & 58 Machines Built May 1992 to
Present Only.
57
3900175
Setscrew 1/4”-28NF x 3/4”
3
3321401
Nut 1/4”-28NF
3
3960416
Seal, Thread
3
58
4640509
Valve, Cartridge (Counterbalance)
2
2900792
Seal Kit - 4640509 Valve (1 Per Cartridge)
2
FIGURE 5-1. AXLE LOCKOUT CYLINDER ASSEMBIES (USE WITH OPTIONAL OSCILLATING AXLE)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
