3120290 4-27
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
103 (cont’d) With Prop Tele: 1
3252139 Lid (Prior to May 1994)
3252364 Lid (May 1994 to Present)
Consult Factory
Plate, Console Decal Mounting (November 1994
to Present)
1
Consult Factory Decal, Console (November 1994 to Present) 1
104 Switch, Toggle - DPDT/MC/CO Options: 1
4360202 Without Prop Tele
Not Required With Prop Tele
105 Controller, PQ Options: A/R
Not Required Without Prop Tele 0
1600141 With Prop Tele 1
7011907 Electrical Assembly 1
106 Knob Options: 1
Not Required Without Prop Tele
2560112 With Prop Tele
107 Not Required
0860744
CONSOLE BOX ASSEMBLY - MACHINES WITH 4WS
AND WITHOUT PROP TELE (VARIABLE PARTS)
Ref. 8
0860842
CONSOLE BOX ASSEMBLY - MACHINES WITH 4WS
AND WITHOUT PROP TELE (VARIABLE PARTS)
Ref. 7
0860746
CONSOLE BOX ASSEMBLY - MACHINES WITH 4WS
AND WITH PROP TELE (VARIABLE PARTS)
Ref. 8
201 1600140 Controller, PQ 1
7011903 Electrical Assembly 1
7003789 Switch, Steer 1
202 Not Required
203 Lid Options: 1
Without Prop Tele:
3252140 Lid (Prior to May 1994)
3252353 Lid (May 1994 to November 1994)
3538394
Plate, Console Decal Mounting (November 1994
to Present)
1
1702404 Decal, Console (November 1994 to Present) 1
With Prop Tele: 1
3252139 Lid (Prior to May 1994)
3252364 Lid (May 1994 to Present)
204 Switch, Toggle - DPDT/MC/CO Options: 1
4360202 Without Prop Tele
Not Required With Prop Tele
205 Controller, PQ Options: A/R
Not Required Without Prop Tele 0
1600141 With Prop Tele 1
7011907 Electrical Assembly 1
206 Knob Options: 1
Not Required Without Prop Tele
2560112 With Prop Tele
FIGURE 4-6. CONSOLE BOX ASSEMBLY - PQ CONTROLLERS AND VICKERS PROP VALVE
(MACHINES BUILT SEPTEMBER 1991 TO PRESENT) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
