1-60 3120290
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
106 4640363 Solenoid Valve Assembly 1
7000558 Coil (FPS Version) 1
7001506 Seal Kit (FPS Version) 1
7004368 Coil (Hydraforce Version) 1
2900795 Seal Kit (Hydraforce Version) 1
107 0641522 Bolt 5/16” - 18NC x 2 3/4” 2
COUNTERBALANCE VALVE AND FLOW DIVIDER
INSTALLATIONS
Ref.
0236590
ALL MACHINES BUILT PRIOR TO MID 1987 WITH
CESSNA MOTORS AND RACINE VALVES
Ref. -
0238014
2WD MACHINES BUILT 1987 TO MARCH 1991 WITH
VICKERS MOTORS AND VICKERS VALVES
Ref. -
0251823
(2WD MACHINES BUILT MARCH 1991 TO MAY 1992
WITH VICKERS MOTORS AND VICKERS VALVES
Ref. A
0238014
4WD MACHINES BUILT 1987 TO MARCH 1991 WITH
VICKERS MOTOR AND VICKERS VALVES
Ref. -
0251824
4WD MACHINES BUILT MARCH 1991 TO MAY 1992
WITH VICKERS MOTORS AND VICKERS VALVES
Ref. -
0252576
2WD MACHINES BUILT MAY 1992 TO AUGUST 1993
WITH REXROTH MOTORS AND VICKERS VALVES
Ref. -
0254394
2WD MACHINES BUILT AUGUST 1993 TO PRESENT
WITH REXROTH MOTOR AND VICKERS VALVES
Ref. A
0252577
4WD MACHINES BUILT MAY 1992 TO PRESENT
WITH REXROTH MOTORS AND VICKERS VALVES
Ref. -
201 Dual Counterbalance Valve Assembly Options: 1
4640451 Machines Built to Installation p/n 0236590
7010630 Cartridge 2
4640700
Machines Built to Installations p/n 0238014/
0251823/0238014/0251824/0252576/0254394
7011316 Cartridge 2
Note: When replacing cartridges on machines
built 1987 to March 1991, make sure to use
replacement cartridge P/N 7011316 in both
locations on valve. Cartridge P/N 7011316 can
be identified by the letters “CBGH-LCN”
stamped on the hex head. “CGBB-LCN” cannot
be used as an equivalent replacement
4640700
Machines Built to Installations p/n 0252576 &
0254394 (Machines Built May 1992 to August
1993)
7011316 Cartridge 1
4640451
Machines Built to Installations p/n 0252576 &
0254394 (Machines Built August 1993 to Present)
1
7010630 Cartridge 1
4640682 Machines Built to Installation p/n 0252577
7011316 Cartridge 2
202 Flow Divider Assembly Options: 1
4640443
Machines Built to Installations p/n 0236590,
0238014, 0251824
1
2900745 Seal Kit 1
FIGURE 1-17. VALVES INSTALLATION (FRAME MOUNTED) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
