JLG 70H Parts Manual User Manual
Page 13
3120290
1-5
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
16
Cone, Bearing Options:
4
0440019
Standard Machines
0440171
Machines With 750 Capacity
17
Cup, Bearing Options:
4
0440018
Standard Machines
0440170
Machines With 750 Capacity
18
Not Used
19
Not Used
20
3312602
Nut, Jam 1”-80NC
2
21
0440091
Washer, Thrust
3
22
2160002
Fitting, Grease
5
23
Hardware Options:
1
3300175
Locknut (Prior to May 1992)
0642632
Bolt 1”-8NC x 4” (May 1992 to Present)
24
0560605
Block, Tie-Rod (RH)
1
25
3323002
Nut, Jam 1 1/4 - 12NF
1
26
Not Used
Spindle (LH) Options:
1
4130229
Standard Machine (Prior to May 1992)
4130235
Machines With 750 Capacity (Prior to May 1992)
4130250
CSA Machine (Prior to May 1992)
4130275
Standard Machine (May 1992 to Present)
4130278
Machines With 750 Capacity (May 1992 to Pres-
ent)
0960523
Bushing, Bronze
2
27
0642630
Bolt 1”-8NC x 3 3/4”
2
28
3450606
Pin, Cotter 3/16” x 1 1/2”
1
29
3431622
Pin, Clevis 1” x 2 3/4”
1
30
4712600
Flatwasher 1” Narrow
1
31
Not Used
Spindle (RH) Options:
1
4130228
Standard Machine (Prior to May 1992)
4130234
Machines With 750 Capacity (Prior to May 1992)
4130249
CSA Machine (Prior to May 1992)
4130274
Standard Machine (May 1992 to Present)
4130277
Machines With 750 Capacity (May 1992 to Pres-
ent)
0960523
Bushing, Bronze
2
32
3520048
Plug, Tapered (Prior to November 1986 Only)
2
33
0100011
Loctite #242 (Not Shown)
A/R
34
0560605
Block, Tie-Rod (RH Thread) (Used Prior to May
1986)
1
0560714
Block, Tie-Rod (LH Thread) (Used May 1986 to Pres-
ent)
1
35
3323002
Nut, Jam 1 1/4”-12NF (RH Thread) (Used Prior to
May 1986)
1
3300229
Nut, Jam 1 1/4” - 12NF (LH Thread) (Used May 1986
to Present)
1
36
3450810
Pin, Cotter 1/4” x 2 1/2”
2
3451010
Pin, Cotter 5/16” x 2 1/2”
2
FIGURE 1-1. FRAME AND STEERING INSTALLATION - 2WD (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
