3120290 4-25
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
FIGURE 4-6. CONSOLE BOX ASSEMBLY - PQ CONTROLLERS AND VICKERS PROP VALVE
(MACHINES BUILT SEPTEMBER 1991 TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CONSOLE BOX ASSEMBLIES Ref.
CONSOLE BOX ASSEMBLY (STANDARD PARTS) Ref.
1 0860739 Box Weldment 1
2940052 Latch 2
2600105 Hinge (Top) 1
2600132 Hinge (Bottom) 1
3531023 Rear Access Door 1
2 Not Used
3 4420008 Tape, Insulation 69 ft/
1.75cm
4 0100001 Adhesive A/R
5 1600141 Controller, PQ 2
7011907 Electrical Assembly 2
6 2560112 Knob 2
7 4360199 Switch, Toggle - SPST 4
8 4360202 Switch, Toggle - DPDT/MC/CO 3
9 4360200 Switch, Toggle - SPST/MC 1
10 3790012 O-Ring A/R
11 4060229 Shield 5
12 2920015 Lamp 2
13 4360274 Switch, Push Button 2
14 Switch, Emergency Stop Options: 1
4360289 Prior to October 1999
4360475 October 1999 to Present
14A Cap Options: 1
7012611 Cap, Mushroom Head (Used on Switch p/n
4360289)
7012612 Boot (Used on Switch p/n 4360289) 1
7020175 Cap, Red (Used on Switch p/n 4360475)
7020176 Contact Block (Used on Switch p/n 4360475)
15 Block, Contact Options: 1
4360282 Prior to October 1999
4360476 October 1999 to Present
16 0751006 Screw #10-24NC x 3/4” 21
17 4740120 Washer, Nylon 21
18 3300177 Nut, Tinnerman 21
19 4460386 Connector, Strain Relief 1
20 3300147 Nut, Conduit 1
21 0960905 Bushing 1
22 4460052 Connector, Strain Relief 2
23 3300047 Nut, Conduit 2
24 0960239 Bushing 2
25 3640752 Track 1
26 3910608 Screw #6-32NC x 1/2” 2
27 4750600 Flatwasher #6 2
28 4760600 Lockwasher #6 2
