1-12 3120290
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
111 0641606 Bolt 3/8”-16NC x 3/4” 2
112 Not Used
113 0440163 Bearing, Thrust 2
114 4740040 Flatwasher 4
115 4070573 Shim, Axle A/R
116 4220102 Stop, Axle (LH) 1
117 4300034 Stud (Welded on Part) 4
118 4751600 Flatwasher 3/8” 6
119 4761600 Lockwasher 3/8” 19
120 3311601 Nut 3/8”-16NC 5
121 4300048 Stud (Welded on Part) 4
122 4751800 Flatwasher 1/2” 5
123 4761800 Lockwasher 1/2” 4
124 3311801 Nut 1/2”-18NC 4
125 4220103 Stop, Axle (RH) 1
126 3530294 Plate, Protection 2
127 3941608 Setscrew 3/8”-16NC x 1” 12
128 1320125 Clamp, Hose 1
129 4300030 Stud 1
0252273
FRONT AXLE INSTALLATION (FIXED AXLE
MACHINES BUILT MAY 1992 TO PRESENT)
Ref. C
0252272
FRONT AXLE INSTALLATION (OSCILLATING AXLE
MACHINES BUILT MAY 1992 TO PRESENT)
Ref. C
Note: Components for Machines with Towing
Package may vary, see Towing Package Installation.
201 Axle Options: 1
4843985 Axle Weldment (May 1992 to June 1994)
4844807 Axle Weldment (June 1994 to Present)
0961613 Bushing, Bronze (Axle Pivot) 2
3780188 O-Ring (Axle Pivot) 2
0961614
Bushing, Bronze (Kingpin), (May 1992 to June
1994)
4
0961850 Bushing, Bronze (Kingpin), (June 1994 to Present) 4
202 3421995 Pin, Pivot 1
203 0641832 Bolt 1/2”-18NC x 4” 1
204 4761800 Lockwasher 1/2” 1
205 3311801 Nut 1/2”-18NC 1
Note: Items 206-209 Oscillating Axle Only.
206 1682688
Axle Lockout Cylinder Assembly (See Section 5 for
Breakdown)
2
207 3421996 Pin, Attach (Upper) 2
208 3421997 Pin, Attach (Lower) 2
209 3760133 Ring, Retaining 8
210 2160002 Fitting, Grease (Straight) A/R
211 2160001 Fitting, Grease (90°) 4
212 Not Used
213 4070796 Shim, Axle (LH) 3
214 3537016 Plate, Stop 2
FIGURE 1-2. FRAME AND STEERING INSTALLATION - 4WD (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
