JLG 70H Parts Manual User Manual
Page 257
3120290
2-179
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
FIGURE 2-42. GROUND CONTROL COMPONENTS INSTALLATION (MACHINES WITH RACINE
PROPORTIONAL VALVES)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
GROUND CONTROL BOX ASSEMBLIES
Ref.
0236506
MACHINES WITH SOLENOID THROTTLE BUILT
PRIOR TO OCTOBER 1985
Ref.
B
0237067
MACHINES WITH ADECO THROTTLE BUILT OCTO-
BER 1985 TO PRESENT
Ref.
C
1
0860487
Box
1
Lid Options:
1
3251522
Prior to October 1985
3251650
October 1985 to Present
3
2600093
Hinge
1
4
3911006
Screw, Round Head #10-24NC x 3/8”
4
5
4761000
Lockwasher #10
A/R
6
3311001
Nut #10-24NC
A/R
7
3911008
Screw, Round Head #10-24NC x 1/2”
12
8
3740049
Relay - SPDT
12
9
4751000
Flatwasher #10
3
10
3740016
Relay - 3PDT
2
11
4120002
Socket, Relay
2
12
4460263
Strip, Terminal
2
13
3910610
Screw, Round Head #6-32NC x 5/8”
A/R
14
4760600
Lockwasher #6
A/R
15
3310601
Nut #6-32NC
A/R
16
0750806
Screw #8 x 3/4”
2
17
3300177
Nut, Tinnerman
2
18
4280237
Strip, Rubber
33 in
19
0100001
Adhesive (Not Shown)
A/R
20
4460051
Connector, Strain Relief
3
21
3300048
Nut, Conduit
4
22
0960238
Bushing
4
23
4360186
Breaker, Circuit - 35 Amp
1
24
Not Used
25
4360069
Breaker, Circuit - 10 Amp
3
26
4360003
Switch, Key
1
2860002
Key, Replacement
1
27
4360073
Switch, Toggle
1
28
4360199
Switch, Toggle
1
29
4360016
Switch, Push Button
1
0840004
Boot
1
30
4360202
Switch, Toggle
3
31
4360204
Switch, Toggle
1
32
4460071
Connector, Strain Relief
1
33
3911012
Screw, Round Head #10-24NC x 3/4”
A/R
34
3790012
O-Ring
6
35
Flasher Options:
1
4360089
Prior to October 1985
Not Required
October 1985 to Present
