3120290 4-35
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
FIGURE 4-8. CONSOLE BOX ASSEMBLY - HYDRAULIC CONTROLS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CONSOLE BOX ASSEMBLIES Ref.
0250067
CONSOLE BOX ASSEMBLY - MACHINES WITHOUT
CAPACITY INDICATOR
Ref. J
0239229
CONSOLE BOX ASSEMBLY - STANDARD
MACHINES WITH CAPACITY INDICATOR AND
STANDARD PLATFORMS
Ref. 16
0250674
CONSOLE BOX ASSEMBLY - CSA MACHINES WITH
CAPACITY INDICATOR AND STANDARD
PLATFORM
Ref. H
0254246
CONSOLE BOX ASSEMBLY - MACHINES WITH
CAPACITY INDICATOR AND LOW MOUNT
PLATFORM
Ref. D
1 0860565 Box Weldment 1
2950052 Latch 1
2600132 Hinge (Top to Bottom) 1
2600105 Hinge (Access Door) 1
3531023 Door, Access (Rear) 1
2 Lid Options: 1
3251858 Lid (Prior to May 1994)
3252374 Lid (May 1994 to November 1994)
3538391
Plate, Console Decal Mounting (November 1994 to
Present)
1702401 Decal, Console (November 1994 to Present)
3 4420008 Tape, Insulation
69 in/
1.75m
4 0100001 Adhesive (Not Shown) A/R
5 0100009 Silicone, RTV (Not Shown) A/R
6 3960251 Gasket 1
7 Not Used Capacity Options: 1
Capacity Decal Options (Machines Without Capac-
ity Indicator):
3251551 Decal (Prior to May 1994)
3252394 Decal (May 1994 to Present)
29600006
Lens, Capacity Indicator (Machines With Capacity
Indicator)
8 3911014 Screw, Round Head #10-24NC x 7/8” 4
9 4771000 Starwasher #10 4
10 3311001 Nut #10-24NC 8
11 Controller Options: 3
4640559 Controller (Prior February 1992)
4640748 Controller (February 1992 to Present)
7009352 Boot (1 Per Assembly) A/R
7012314 Lever Kit (1 Per Assembly) A/R
7012316 Spring, Handle Lock (1 Per Assembly) A/R
12 4360209 Breaker, Circuit - 20 Amp 1
13 4360202 Switch, Toggle - DPDT/MC/CO 3
14 Switch, Shield Options: A/R
4060087 Shield (Prior to May 1994)
4060229 Shield (May 1994 to Present)
