JLG 70H Parts Manual User Manual
Page 118
2-40
3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
133
7012333
Load Sense (2 Per Section)
A/R
134
Kit
O-Ring (2 Per Section)
A/R
135
Kit
O-Ring (2 Per Section)
A/R
136
Kit
O-Ring (5 Per Section)
A/R
137
Kit
O-Ring (2 Per Section)
A/R
138
Not Serviced
Cap, End (2 Per Section)
A/R
— — — — — — — — — —
7009330
Seal Kit (1 Per Section)
A/R
7012383
Piston/Spring Kit (Includes Items 1 each of Items
100, 102, 103, 106 and 107) (2 Per Section)
A/R
150
#1 WORKING SECTION OPTIONS:
1
7012332
Drive (All Models)
151
7012331
Spool
1
152
7009399
Poppet
2
153
Not Required
Piston
0
150
#2 WORKING SECTION OPTIONS:
1
7012334
Lift (All Models)
151
7012331
Spool (1 Per Section)
1
152
7009397
Poppet (2 Per Section)
2
153
Not Required
Piston
0
150
#3 WORKING SECTION OPTIONS:
1
7012335
Swing (“H” and “HX” Models Without Prop.
Tele.)
151
7012340
Spool
1
152
7009399
Poppet
2
153
7012300
Piston
2
7012334
Telescope (“H” and “HX” Models With Prop.
Tele.)
70123334
Lift (“HA” Models)
151
7012331
Spool
1
152
7009397
Poppet
2
153
Not Required
Piston
0
150
#4 WORKING SECTION OPTIONS:
1
Not Required
(“H” and “HX” Models Without Prop. Tele.)
7012335
Swing (“H” and “HX” Models With Prop. Tele.)
7012335
Swing (“HA” Models)
151
7012340
Spool
1
152
7009399
Poppet
2
153
7012300
Piston
2
OUTLET SECTION
Ref.
201
7006782
Nut
6
202
7009361
Rod, Tie
3
203
7012337
Cover End
1
FIGURE 2-9. VICKER PROPORTIONAL CONTROL VALVE ASSEMBLY (STANDARD CONTROLS)
(OCTOBER 1994 TO PRESENT) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
