3120290 3-3
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
FIGURE 3-1. BOOM COMPONENT ASSEMBLIES
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
BOOM COMPONENT ASSEMBLIES Ref.
0800392
BOOM ASSEMBLY - 60H WITH STANDARD CON-
TROL
Ref. 27
0800577
BOOM ASSEMBLY - 60H WITH HYDRAULIC
CONTROL
Ref. 12
0800505
BOOM ASSEMBLY - 60H+6 WITH STANDARD
CONTROL
Ref. 9
0800418
BOOM ASSEMBLY - 70H WITH STANDARD
CONTROL
Ref. 21
0800631
BOOM ASSEMBLY - 70H WITH HYDRAULIC
CONTROL
Ref. 13
1 Boom Base Weldment Options: A/R
0800391 60H/60H+6 1
0960985 Bushing 2
0800421 70H 1
0960985 Bushing 2
2 Boom Mid Weldment Options: 1
0800390 60H with Standard Control
60H with Hydraulic Control
0800390 Mid (Prior to July 1991)
0800744 Mid (July 1991 to Present)
0800390 60H+6 with Standard Control
0800420 70H with Standard Control
70H with Hydraulic Control
0800420 Mid (Prior to March 1992)
0800751 Mid (March 1992 to Present)
3 Boom Fly Weldment Options: 1
60H with Standard Control
0800389 Fly (Prior to June 1985)
0800417 Fly (June 1985 to Present)
1320052 Clamp 1
3421088 Boom Pin Assembly (Includes Hardware) 1
0800417 60H with Hydraulic Control
1320052 Clamp 1
3421088 Boom Pin Assembly (Includes Hardware) 1
0800471 60H+6 with Standard Control
1320052 Clamp 1
0800419 70H with Standard Control
1320052 Clamp 1
3421088 Boom Pin Assembly (Includes Hardware) 1
0800419 70H with Hydraulic Control
1320052 Clamp 1
4
Telescope Cylinder Assembly Options (See Section 5
for Breakdown):
1
1681516 60H/60H+6
70H Options:
1681574 Cylinder (Prior to December 1986)
1681813 Cylinder (December 1986 to Present)
