JLG 70H Parts Manual User Manual
Page 316
4-18
3120290
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
6
2560038
Knob, Controller (Lift)
1
7
2560041
Knob, Controller (Drive)
1
8
3960251
Gasket
1
9
Decal - Capacity Options:
1
3251551
Machines Without Capacity Indicator
2960006
Machines With Capacity Indicator
Not Required
CSA 2WD Machines With Vickers Prop Valve And
With Capacity Indicator
10
3911014
Screw, Round Head #10-24NC x 7/8”
4
11
4771000
Starwasher #10
4
12
3311001
Nut #10-24NC
6
13
2920015
Lamp
1
14
4360274
Switch, Push Button
2
15
Shield, Switch Options:
A/R
4060087
All Machines except CSA 2WD
A/R
4060229
CSA 2WD Machines With Vickers Prop Valve And
With Capacity Indicator
9
16
4360202
Switch, Toggle
4
17
4360199
Switch, Toggle
4
18
Switch, Toggle Options:
1
4360204
Machines With Racine Valves
4360200
Machines With Vickers Valve
19
4360141
Guard, Switch
1
20
4420038
Tape, Insulation
34 in.
21
0100001
Adhesive (Not Shown)
A/R
22
0751006
Screw #10-24NC x 3/4”
15
23
3300177
Nut, Tinnerman
15
24
3960250
Weatherstrip
16”
25
0100009
Silicone-RTV (Not Shown)
A/R
26
0860472
Box, Weldment
1
27
4460263
Strip, Terminal
1
28
3911012
Screw, Round Head #10-24NC x 3/4”
2
29
4761000
Lockwasher #10
6
30
Not Used
31
3300048
Locknut, Conduit
2
32
4460071
Connector, Strain Relief
1
33
4460051
Connector, Strain Relief
1
34
3300047
Locknut, Conduit
1
35
4460052
Connector, Strain Relief
1
36 to 40
Not Used
41
0100011
Loctite #242 (Not Shown)
A/R
42
3311405
Locknut 1/4”-20NC
4
43
3509858
Plate, Rear Cover
1
44
4751400
Flatwasher 1/4”
8
45
0641407
Bolt 1/4”-20NC x 7/8”
4
46
3790012
O-Ring
A/R
47
0860038
Box, Receptacle
1
48
Not Used
49
4460049
Connector, Strain Relief
1
FIGURE 4-4. CONSOLE BOX ASSEMBLIES - PQ CONTROLLERS WITHOUT PROP TELE
(MACHINES BUILT PRIOR TO SEPTEMBER 1991) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
