2-180 3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
36 Clamp Options: 1
1320060 Prior to October 1985
Not Required October 1985 to Present
37 4360212 Breaker, Circuit - 3 Amp (October 1985 to Present) 1
HARNESS INSTALLATIONS OPTIONS: Ref.
0860501
MACHINES WITHOUT PROP TELE AND WITH
SOLENOID THROTTLE BUILT PRIOR TO OCTO-
BER 1985
Ref. -
0860508
MACHINES WITHOUT PROP TELE AND WITH
ADECO THROTTLE BUILT OCTOBER 1985 TO
DECEMBER 1985
Ref. A
0860518
MACHINES WITHOUT PROP TELE AND WITH
ADECO THROTTLE BUILT DECEMBER 1985 TO
PRESENT
Ref. -
0860488
MACHINES WITH PROP TELE AND WITH SOLE-
NOID THROTTLE BUILT PRIOR TO OCTOBER
1985
Ref. -
0860519
MACHINES WITH PROP TELE AND WITH ADECO
THROTTLE BUILT OCTOBER 1985 TO PRESENT
Ref. -
101 Harness - 16/24 to Boom Options: 1
4920454
Machines Without/With Prop Tele and with Sole-
noid Throttle (Prior to October 1985)
Not Required
Machines Without/With Prop Tele and with
Adeco Throttle (October 1985 to Present)
102 Harness - 12/4 to Boom Options: 1
4920455
Machines Without/With Prop Tele and with Sole-
noid Throttle (Prior to October 1985)
Not Required
Machines Without/With Prop Tele and with
Adeco Throttle (October 1985 to Present)
103 Harness - Box to Engine Options: 1
4920463
Machines Without/With Prop Tele and with Sole-
noid Throttle (Prior to October 1985)
4920528
Machines Without/With Prop Tele and with
Adeco Throttle (October 1985 to Present)
104 Harness - Box to Valves Options: 1
4920462
Machines Without Prop Tele and with Solenoid
Throttle (Prior to October 1985)
4920461
Machines With Prop Tele and with Solenoid
Throttle (Prior to October 1985)
4920461
Machines Without Prop Tele and with Adeco
Throttle (October 1985 to December 1985)
4920462
Machines With Prop Tele and with Adeco Throt-
tle (October 1985 to Present)
105
Ground Control Box Assembly (See Items 1-54 for
Breakdown)
1
0236506
Machines Without/With Prop Tele and with Sole-
noid Throttle (Prior to October 1985)
0236506
Machines Without Prop Tele and with Adeco
Throttle (October 1985 to December 1985)
FIGURE 2-42. GROUND CONTROL COMPONENTS INSTALLATION (MACHINES WITH RACINE
PROPORTIONAL VALVES) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
