JLG 70H Parts Manual User Manual
Page 298
3-14
3120290
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
19
Pin Options:
1
3421513
Standard (Prior to S/N 40600)
3422768
Standard (S/N 40600 to Present)
3421821
CSA Spec (Prior to S/N 40600)
3422766
CSA Spec (S/N 40600 to Present)
20
2160002
Fitting, Grease
6
21
3760133
Ring, Retaining (Prior to February 1991)
1
22
Pin Options:
1
3421429
Prior to February 1991
3421950
February 1991 to Present
3421950
CSA Spec
23
3421376
Pin
1
24
Not Used
25
Not Used
26
Not Used
27
Not Used
28
1320145
Clamp
2
29
0361524
Bar
2
30
3311605
Locknut 3/8”-16NC
4
31
Not Used
32
Not Used
33
Not Used
34
Not Used
35
Not Used
36
4300076
Stud 3/8”-16NC x 3 (Welded on Parts) (Not Shown)
4
37
3311602
Nut, Jam 3/8”-16NC
4
38
1670456
Cover, Hose
1
39
Not Used
40
2880508
Keystock (Not Shown) (Prior to S/N 40600)
1
41
4740390
Washer
1
42
0741606
Screw, Countersunk 3/8”-16NC x 3/4”
1
FIGURE 3-3. EXTEND-A-REACH INSTALLATIONS (60H+6 MACHINES) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
