Page 109

Xerox 4595 Copier/Printer System Administration Guide
5-19
5. Using the Scan Service
6.
Select
Close
repeatedly until the
System Settings
screen is
displayed.
7.
Select
Exit
.
8.
After the machine is restarted, print out the
Printer Settings
List
to confirm that the ports are enabled and TCP/IP is
configured.
Configuring the SNMP port
Configure the transport protocol for the SNMP port using
CentreWare Internet Services.
1.
Start a web browser.
2.
Enter the machine’s IP address or the Internet address to the
address entry column on the browser, and press the Enter key.
•
Example of the IP address entry:
http://192.168.1.1/
•
Example of the Internet address entry:
http://xxx.yyyy.zz.vvv/
NOTE: When specifying a port number, add “:” and a port
number to the end of the Internet address.
3.
Click the
Properties
tab.
4.
Click
Port Status
from the
Properties
area.
5.
Select the
UDP
checkbox to the right of
SNMP
(Port Status
feature).
6.
Reflect the values as the setting values of the machine.
a. Click the
Apply New Settings
.
b. Enter the System Administrator UserID and password into
User Name
and
Password
, and then click
OK
.
NOTE: The default User ID value is 11111 and password is x-
admin.
c. The right frame on the web browser will change to the
machine reboot display.
d. Click
Reboot
. The machine will reboot and the setting
value will be reflected.
