70 | Configuring connectors
Configuring the fax address format
For fax connectors, you must define the fax address format required by your fax server application
or Internet fax service.
To configure the fax address format:
1 In the console tree, click the name of the fax connector.
2 On the Fax Format tab, click the Format button. The Fax Address Format window opens.
3 Refer to the documentation for your fax application to obtain the correct format for fax
addresses. A sample format is shown below:
1 Start building the address by adding components. For example, to include a prefix, select Prefix
from the list on the left and then click Add .
2 You can re-order the fax address components using the Move Up and Move Down buttons.
Important! Since fax application vendors change these formatting schemes frequently, make
sure you obtain the current format.
[FAX:Jane Doe@/FN=555-1212/CS=]
Recipient Name Fax Number
Name Separator
Prefix
Fax Prefix Cover Page Attached
Suffix
