Chapter 3: Basic Switch Parameters
76 Section I: Basic Features
Displaying Uplink Port Information
To display the information about the GBIC or SFP transceivers installed in
the uplink ports, perform the following procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 51.
2. From the System Administration menu, type 1 to select System
Information
The System Information menu is shown in Figure 6 on page 56.
3. From the System Information menu, type U to select Uplink
Information.
The Uplink Information menu is shown in Figure 14.
Figure 14. Uplink Information Menu
The Uplink Information menu displays the status of the GBIC/SFP
uplink ports, ports 23 and 24. If a GBIC or an SFP transceiver is
installed in one of the slots, the display shows “Present.” “Not
Present” indicates that no GBIC or SFP transceiver is installed in
that slot.
Note
The Uplink Information menu only indicates that a GBIC or an SFP is
inserted in the slot. It does not indicate whether or not a fiber optic
cable is connected to the GBIC or SFP.
4. Type the number corresponding to the slot where the transceiver is
identified as “Present” to view detailed information about that
transceiver. The information displayed depends upon the transceiver
vendor and whether the slot contains an SFP or a GBIC transceiver.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Uplink Information
1 - GBIC/SFP 1 ............ Not Present
2 - GBIC/SFP 2 ............ Present
R - Return to Previous Menu
Enter your selection?
