AT-S63 Management Software Menus Interface User’s Guide
Section III: VLANs 495
The GVRP State Machine menu (page 2) is displayed, as shown in
Figure 159.
Figure 159. Display GVRP State Machine Menu (page 2)
The information in the menu is defined in Table 22. This
information is for viewing purposes only.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
GVRP State Machine
State Machine for VLAN: 1
Port App Reg | Port App Reg | Port App Reg | Port App Reg |
------------------------------------------------------------------
1 Aa Fix | 2 Aa Fix | 3 Vo Mt | 4 Vo Fix |
5 VO Fix | 6 Vo Fix | 7 VO Mt | 8 Vo Fix |
9 Vo Fix | 10 Vo Fix | 11 Vo Mt | 12 Vo Fix |
13 Vo Fix | 14 Vo Fix | 15 Vo Mt | 16 Vo Fix |
17 Aa Fix | 18 Vo Fix | 19 Vo Mt | 20 Vo Fix |
21 Vo Mt | 22 Vo Mt | 23 Aa FIx | 24 Aa Fix |
-----------------------------------------------------------------
U - Update Display
R - Return to Previous Menu
Enter your selection?
Table 22. GVRP State Machine Parameters
Parameter Meaning
Port Port number on the switch; this port belongs to
the GARP application. If the GARP application
has no ports, “No ports have been assigned” is
displayed.
