AT-S63 Management Software Menus Interface User’s Guide
Section IV: Security 639
Displaying the Port Access Parameters
To display the port access parameters for the ports on the switch,
perform the following procedure:
1. From the Main Menu, type 8 to select Security Configuration.
The Security Configuration menu is shown in Figure 175 on page
559.
2. From the Security Configuration menu, type 1 to select Port Access
Control (802.1X).
The Port Access Control (802.1X) menu is shown in Figure 197 on
page 629.
3. From the Port Access Control menu, type 6 to select Display Port
Access status.
The Display Port Access Status menu is shown in Figure 203.
Figure 203. Display Port Access Status Menu
The Display Port Access Status menu displays a table that contains
the following columns of information:
Port
Port number.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Display Port Access Status
Port PortRole State Additional Info
---------------------------------------------------------------
1
None ------ -------------------
2 Authenticator Connecting -------------------
3 Authenticator Authenticated 00:a0:d2:18:1a:c8
4 Authenticator Connecting -------------------
5 None ------ -------------------
6 None ------ -------------------
7 None ------ -------------------
8 Supplicant ------ --------------------
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
