Allied Telesis AT-S63 - Manual (Page 652)

Chapter 30: TACACS+ and RADIUS Protocols
Section IV: Security 652
Displaying the TACACS+ Settings
To display the TACACS+ settings, perform the following procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 51.
2. From the System Administration menu, type 6 to select
Authentication Configuration.
The Authentication Configuration menu is shown in Figure 205 on
page 648.
3. Type 3 to select TACACS+ Configuration.
The TACACS+ Client Configuration menu is shown in Figure 207.
Figure 207. TACACS+ Client Configuration Menu
The TACACS+ Client Configuration menu provides the following
information:
TAC Server 1
TAC Server 2
TAC Server 3
The IP addresses of the TACACS+ servers.
TAC Server Order
The order in which the switch to queries the TACACS+ servers for
logon authentication.
TAC Global Secret
Global encryption secret if all the servers use the same one.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
TACACS+ Client Configuration
1 - TAC Server 1 .................. 142.34.56.102
2 - TAC Server 2 .................. 0.0.0.0
3 - TAC Server 3 .................. 0.0.0.0
4 - TAC Server Order .............. 1 2 3
5 - TAC Global Secret ............. tech
6 - TAC Timeout ................... 30 seconds
R - Return to Previous Menu
Enter your selection?
