Displaying VLANs
To view the name, VID number, and member ports of all the VLANs on a
switch, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 135 on page
441.
2. From the VLAN Configuration menu, type 5to select Show VLANs.
The Show VLANs menu is shown in Figure 140.
Figure 140. Show VLANs Menu
The Show VLANs menu displays a table that contains the
following columns of information:
VID
The VLAN ID.
VLAN Name
Name of the VLAN.
VLAN Type
The VLAN type. The possible settings are:
Port Based - The VLAN is a port-based or tagged VLAN.
GARP - The VLAN was automatically created by GARP.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager
11:20:02 02-Oct-2004
Show VLANs
VID VLAN Name
VLAN Type
Protocol
Untagged (U) / Tagged (T)
------------------------------------------------------------------
1
Default_VLAN
Port Based
U: 20-24
Port Based
T: 7,9
2
Sales
Port Based
U: 1-7
Port Based
T: 9
3
Production
Port Based
U: 8-19
Port Based
T: 7
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
