AT-S63 Management Software Menus Interface User’s Guide
Section III: VLANs 511
An example of the Show VLANs window is shown in Figure 163.
Figure 163. Show VLANs Menu
Section 1 lists all the tagged and untagged ports in the protected
ports VLAN.
Section 2 lists each group in the VLAN, starting with the uplink
port(s). The groups are listed by group number followed by the
port numbers. For example, in Figure 163 the uplink port for the
VLAN is port 25 and Group 1 consists of ports 12 and 13.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Show VLANs
VID VLAN Name VLAN Type Protocol Untagged (U) / Tagged (T)
------------------------------------------------------------------
5 Internet_VLAN Protected U: 12-24
Protected T: 25
Group Ports
---------------------------------------------
Uplink
25
1 12-13
2 14-15
3 16
4 17
5 18-20
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
Section 1
Section 2
