AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Features 309
Configuring MSTP Port Settings
To configure a port’s MSTP parameters, perform the following
procedure:
1. From the Main Menu, type 3 to select Spanning Tree Configuration.
The Spanning Tree Configuration menu is shown in Figure 78 on
page 259.
2. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The MSTP menu is shown in Figure 95 on page 294.
3. From the MSTP menu, type P to select MSTP Port Parameters.
The MSTP Port Parameters menu is shown in Figure 99.
Figure 99. MSTP Port Parameters Menu
4. From the MSTP Port Parameters menu, type 1 to select Configure
MSTP Port Settings.
The following prompt is displayed:
Enter port-list:
5. Enter the port to configure.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
MSTP Port Parameters
1 - Configure MSTP Port Settings
2 - Display MSTP Port Configuration
3 - Display MSTP Port State
R - Return to Previous Menu
Enter your selection?
