AT-S63 Management Software Menus Interface User’s Guide
Section III: VLANs 447
Modifying a VLAN
Note
To modify a VLAN, you need to know its VID. To view VLAN VIDs,
refer to ”Displaying VLANs” on page 451.
To modify a VLAN, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 135 on page
441.
2. From the VLAN Configuration menu, type 4 to select Configure
VLANs.
The Configure VLANs menu is shown in Figure 136 on page 442.
Note
If selection 4, Configure VLANs, is not displayed in the menu, the
switch is running a multiple VLAN mode. To change a switch’s VLAN
mode, refer to ”Selecting a VLAN Mode” on page 468.
3. From the Configure VLANs menu, type 2 to select Modify VLAN.
The Modify VLAN menu is shown in Figure 138.
Figure 138. Modify VLAN Menu
Note
Selection 2, Change GARP VLAN, is described in Chapter 21, ”GARP
VLAN Registration Protocol” on page 471.
4. Type 1 to select VLAN ID (VID).
The following prompt is displayed:
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Modify VLAN
1 - VLAN ID (VID) ........
2 - Change GARP VLAN
R - Return to Previous Menu
Enter your selection?
