AT-S63 Management Software Menus Interface User’s Guide
Section IV: Security 537
Displaying the ACEs
To display the ACEs, perform the following procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 51.
2. From the System Administration menu, type 7 to select Management
ACL menu.
The Management ACL menu is shown in Figure 171 on page 532.
3. From the Management ACL menu, type 4 to select Display All
Management ACL Entries.
A list of the ACEs along with the specifics of each ACE is displayed
at the bottom of the Management ACL menu, as shown in
Figure 172.
Figure 172. Management ACL Menu with ACEs Display
The Management ACL menu provides the following information
about the ACEs:
IP Address
The IP address of a management station.
Mask
The parts of the IP address the switch is filtering on.
Protocol
The protocol used for management packets.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Management ACL Menu
Configuring Management ACL
1 - Management ACL Status ........... Disabled
2 - Add Management ACL Entry
3 - Delete Management ACL Entry
4 - Display All Management ACL Entries
R - Return to Previous Menu
Enter your selection? 4
IP Address
Mask Protocol Interface
133.22.145.18 255.255.255.255 TCP & UDP All
Press any key to continue
