Chapter 7: MAC Address Table
134 Section I: Basic Features
Type
The type of the address: static or dynamic.
An example of a multicast MAC address table is shown in Figure
38.
Figure 38. Display All Menu - Multicast MAC Addresses
The multicast MAC address table contains the following columns
of information:
MAC Address
The static or dynamic unicast MAC address.
VLAN ID
The ID number of the VLAN where the port is an untagged
member.
Type
The type of the address: static or dynamic.
Port Maps
The tagged and untagged ports on the switch that are members
of a multicast group. This column is useful in determining which
ports belong to different groups.
The other selections on the menu are:
2 - Display Static
This selection displays only the static addresses assigned to the
ports on the switch.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Display All
Page 1
Total Number of MCAST MAC Addresses: 1
MAC Address VLANID Type Port Maps (U:Untagged T:Tagged)
----------------------------------------------------------------
01:00:51:00:00:01 1
Static U:1-4
T:
U - Update Display
R - Return to Previous Menu
Enter your selection?
