Chapter 14: IGMP Snooping
242 Section II: Advanced Features
Displaying a List of Multicast Routers
A multicast router is a router that is receiving multicast packets from a
multicast application and transmitting the packets to host nodes. You
can use the AT-S63 management software to display a list of the
multicast routers that are connected to the switch.
To display a list of the multicast routers, perform the following
procedure:
1. From the Main Menu, type 6 to select Advanced Configuration.
The Advanced Configuration menu is shown in Figure 69 on page
236
2. From the Advanced Configuration menu, type 1 to select IGMP
Snooping Configuration.
The IGMP Snooping Configuration menu is shown in Figure 70 on
page 236.
3. From the IGMP Snooping Configuration menu, type 7 to select View
Multicast Routers List.
The View Multicast Routers List menu is shown in Figure 72.
Figure 72. View Multicast Routers List Menu
The View Multicast Routers List menu displays a table that
contains the following columns of information:
VLAN
The VID of the VLAN in which the port is an untagged member.
Port/Trunk ID
The port on the switch where the multicast router is connected.
Allied Telesyn Ethernet Switch AT-9424T/SP - ATS63 v1.0.0
Production Switch
User: Manager 11:20:02 02-Jan-2004
View Multicast Routers List
VLAN Port/Trunk ID RouterIP
----------------------------------------------------
1
14 172.16.01.1
U - Update Display
R - Return to Previous Menu
Enter your selection?
