Chapter 14: IGMP Snooping
240 Section II: Advanced Features
Displaying a List of Host Nodes
You can use the AT-S63 management software to display a list of the
multicast groups on a switch, as well as the host nodes. To display the
list, perform the following procedure:
1. From the Main Menu, type 6 to select Advanced Configuration.
The Advanced Configuration menu is shown in Figure 69 on page
236
2. From the Advanced Configuration menu, type 1 to select IGMP
Snooping Configuration.
The IGMP Snooping Configuration menu is shown in Figure 70 on
page 236.
3. From the IGMP Snooping Configuration menu, type 6 to select View
Multicast Hosts List.
The View Multicast Host List menu is shown in Figure 71.
Figure 71. View Multicast Hosts List Menu
The View Multicast Hosts List menu displays a table with the
following columns of information:
Multicast Group
The multicast address of the group.
VLAN
The VID of the VLAN in which the port is an untagged member.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
View Multicast Hosts List
MulticastGroup VLAN Port/Trunk HostIP Status
-----------------------------------------------------------
01:00:5E:00:01:01
1 6 172.16.10.51 Active
01:00:5E:7F:FF:FA 1 5 149.35.200.75 Active
149.35.200.65 Active
01:00:5E:00:00:02 1 17 149.35.200.69 Active
01:00:5E:00:00:09 1 14 172.16.10.51 Active
U - Update Display
R - Return to Previous Menu
Enter your selection?
