Chapter 11: File Downloads and Uploads
200 Section I: Basic Features
Downloading a
System File
from a Telnet
Management
Session
To download a system file onto a switch from a Telnet management
session using TFTP, perform the following procedure:
1. Establish a Telnet management session on the switch where you
intend to download the new file.
2. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 51.
3. From the System Administration menu, type 9 to select System
Utilities.
The System Utilities menu is shown in Figure 7 on page 58.
4. From the System Utilities menu, type 2 to select Downloads and
Uploads.
The Downloads and Uploads menu is shown in Figure 52 on page
187.
Note
Options 3 and 4 in the menu are described in ”Uploading a System
File” on page 201.
5. From the Downloads and Uploads menu, type 3 to select Download a
File.
The following prompt is displayed:
Only TFTP downloads are available for a Telnet access
TFTP Server IP address:
6. Enter the IP address of the TFTP server.
The following prompt is displayed:
Remote File Name:
7. Enter the directory path and file name of the system file you want to
download.
The following message is displayed:
Getting the file from Remote TFTP Server - Please wait
...
8. If you have not already done so, start the TFTP server software.
After the switch has downloaded the system file, the following
message is displayed:
File received successfully!
