Page 73

AT-S63 Management Software Menus Interface User’s Guide
Section I: Basic Features
73
Displaying and Setting System Hardware Information
You can view information about the system hardware, including details
about the fans and temperature settings.
Displaying
System
Hardware
Information
To display the system hardware information, perform the following
procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 51.
2. From the System Administration menu, type 1 to select System
Information
The System Information menu is shown in Figure 6 on page 56.
3. From the System Information menu, type H to select System
Hardware Status.
Note
Menu selection U, Uplink Information, is described in ”Displaying
Uplink Port Information” on page 76.
The System Hardware Status menu is shown in Figure 12.
Figure 12. System Hardware Information Menu
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager
11:20:02 02-Oct-2004
System Hardware Status
System 1.25 V Power ............. 1.28V
System 1.8V Power ............... 1.76V
System 2.5V Power ............... 2.48V
System 3.3V Power ............... 3.2V
System 5V Power ................. 5.0V
System 12V Power ................ 11.68V
System Temperature (Celsius) .... 36 C
System Fan Speed ................ 3970 RPM
Main PSU ........................ On
RPS ............................. Not Connected
U - Update Display
R - Return to Previous Menu
Enter your selection?
