AT-S63 Management Software Menus Interface User’s Guide
Section III: VLANs 487
Figure 155. GVRP Counters Menu (page 2)
The GVRP counters in the menus are described in Table 21.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
GVRP Counters
Receive: Transmit:
--------
---------
GARP Messages:
---------------
LeaveAll
7 LeaveAll 77
JoinEmpty 0 JoinEmpty 58
JoinIn 68 JoinIn 285
LeaveEmpty 0 LeaveEmpty 1
LeaveIn 0 LeaveIn 0
Empty 5 Empty 21
Bad Message 0
Bad Attribute 0
P - Previous Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
Table 21. GVRP Counters
Parameter Meaning
Receive: Total GARP
Packets Total number of GARP PDUs received by this
GARP application.
Transmit: Total GARP
Packets Total number of GARP PDUs transmitted by
this GARP application.
Receive: Invalid GARP
Packets Number of invalid GARP PDUs received by this
GARP application.
Receive Discarded:
GARP Disabled Number of received GARP PDUs discarded
because the GARP application was disabled.
Transmit Discarded:
GARP Disabled Number of GARP PDUs discarded because the
GARP application was disabled. This counter is
incremented when ports are added to or
deleted from the GARP application arising
from port movements in the underlying VLAN
or STP.
