Chapter 11: File Downloads and Uploads
188 Section I: Basic Features
The following prompt is displayed:
TFTP Server IP address:
b. Enter the IP address of the TFTP server.
The following prompt is displayed:
Remote File Name:
c. Enter the directory path and file name of the AT-S63 image file
stored on the TFTP server.
The following message is displayed:
Getting the file from Remote TFTP Server - Please
wait ...
d. If you have not already done so, start the TFTP server software.
After the switch has downloaded the image file, the following
message is displayed:
File received successfully!
Note
The switch validates the file and then begins the initialization
process of writing the image to flash. The switch does not forward
any network traffic during the initialization process. After the
management software is initialized, the switch automatically resets.
7. To download a file using Xmodem, type X at the prompt displayed in
Step 5.
The following prompt is displayed:
You are going to invoke the Xmodem download utility.
Do you wish to continue? [Yes/No]
Note: Please select 1K Xmodem protocol for faster
download.
Note
The transfer protocol must be Xmodem or 1K Xmodem.
8. Type Y for Yes.
The prompt “Downloading” is displayed.
9. Begin the file transfer.
Steps 10 through 13 illustrate how you download a file using the
Hilgraeve HyperTerminal program.
