AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Features 273
The Spanning Tree Configuration menu is shown in Figure 78 on
page 259.
2. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The RSTP menu is shown in Figure 79 on page 261.
3. From the RSTP menu, type P to select RSTP Port Parameters.
The RSTP Port Parameters menu is shown in Figure 84 on page
269.
4. From the RSTP Port Parameters menu, type 3 to select Display RSTP
Port State.
The Display RSTP Port State menu is shown in Figure 87.
Figure 87. Display RSTP Port State Menu
The Display RSTP Port State menu displays a table that contains
the following information:
Port
The port number.
State
The RSTP state of the port. The possible states are:
❑ Discarding - The port is discarding received packets and is not
submitting forwarded packets for transmission.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Display RSTP Port State
Port State Role P2P Version Port-Cost
--------------------------------------------------------------
1 Disabled
2
3
4
5
6
7
8
1
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
