AT-S63 Management Software Menus Interface User’s Guide
Section I: Basic Features
41
2. Connect the other end of the cable to an RS-232 port on a terminal or
PC with a terminal emulator program.
3. Configure the terminal or terminal emulation program as follows:
❑ Baud rate: 9600 to 115200 bps
❑ Data bits: 8
❑ Parity: None
❑ Stop bits: 1
❑ Flow control: None
Note
The port settings are for a DEC VT100 or ANSI terminal, or an
equivalent terminal emulator program.
Note
During boot up, the switch displays the following prompt:
Press
. This message is intended for
manufacturing purposes only. (If you inadvertently display the boot
prompt (=>), type boot and press Return to start the switch.)
4. Press Enter.
5. You are prompted for a user name and password.
To configure the switch settings, enter “manager” as the user
name. The default password for manager access is “friend. “ To
just view the settings, enter “operator” as the user name. The
default password for operator access is “operator.” User names
and passwords are case sensitive. For information on the two
access levels, refer to ”Management Access Levels” on page 36.
(For instructions on how to change a password, refer to
”Configuring the Manager and Operator Passwords” on page 60.)
6. The command line interface (CLI) prompt is displayed, as shown in
Figure 2. CLI Prompt
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
#
