AT-S63 Management Software Menus Interface User’s Guide
Section IV: Security 629
Setting Port Roles
This procedure sets port roles. For an explanation of port roles, refer to
”Port Roles” on page 622. You must set up the port roles before you
enable port access control.
To set port roles, perform the following procedure:
1. From the Main Menu, type 8 to select Security Configuration.
The Security Configuration menu is shown in Figure 175 on page
559.
2. From the Security Configuration menu, type 1 to select Port Access
Control (802.1X).
The Port Access Control (802.1X) menu is shown in Figure 197.
Figure 197. Port Access Control (802.1X) Menu
3. From the Port Access Control menu, type 3 to select Configure Port
Access Role.
The following prompt is displayed:
Enter port list ->
4. Enter the port whose role you want to change. You can specify one
port or a range of ports (for example, 4-8), but not nonconsecutive
ports (for example, 4,6,11).
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Port Access Control (802.1X)
1 - Port Access Control .............. Enabled
2 - Authentication Method ............ RADIUS EAP
3 - Configure Port Access Role
4 - Configure Authenticator
5 - Configure Supplicant
6 - Display Port Access Status
7 - Configure Accounting
R - Return to Previous Menu
Enter your selection?
