AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Features 305
The VLAN-MSTI Association menu is shown in Figure 98.
Figure 98. VLAN-MSTI Association Menu
The VLAN-MSTI Association menu displays a table that contains
the following columns of information:
MSTI / CIST
Lists the CIST and current MSTI IDs on the switch.
Associated VLANs
Specifies the VIDs of the VLANs associated with the CIST and MSTI
IDs. For instance, referring to Figure 98, the VLANs with the VIDs 7
and 22 are assigned to MSTI 7.
Associating a
VLAN to an
MSTI ID
To associate a VLAN to an MSTP ID, perform the following procedure:
1. From the Main Menu, type 3 to select Spanning Tree Configuration.
The Spanning Tree Configuration menu is shown in Figure 78 on
page 259.
2. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The MSTP menu is shown in Figure 95 on page 294.
3. From the MSTP menu, type M to select MSTI menu.
The MSTI menu is shown in Figure 97 on page 299
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
VLAN-MSTI Association Menu
MSTI/CIST Associated VLANs
-------------------------------------------------------
0
4
1,2
5 6
7 7,22
1 - Add VLANs to MSTI
2 - Delete VLANs from MSTI
3 - Set VLAN to MSTI Association
4 - Clear VLAN to MSTI Association
U - Update Display
R - Return to Previous Menu
Enter your selection?
