Chapter 21: GARP VLAN Registration Protocol
490 Section III: VLANs
Displaying the GVRP Database
To display GVRP database, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 135 on page
441.
2. From the VLAN Configuration menu, type 8 to select Configure GARP-
GVRP.
The GARP-GVRP menu is shown in Figure 149 on page 480.
3. From the GARP-GVRP menu, type O to select Other GVRP Parameters
menu.
The Other GARP Port Parameters menu is shown in Figure 153 on
page 485.
4. From the Other GARP Port Parameters menu, type 2 to select Display
GVRP Database
The GVRP Database menu is shown in Figure 156.
Figure 156. GVRP Database Menu
The GVRP Database menu displays a table that contains the
following columns of information:
GARP Application
Identifies the GARP application, that is, “GVRP”.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
GVRP Database
GARP Application: GVRP
GID index
VLAN ID Used GID index VLAN ID Used
------------------------ -----------------------------
0 1 Yes 1 3 Yes
2 2 Yes
U - Update Display
R - Return to Previous Menu
Enter your selection?
