AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Features 215
Figure 62 shows an example of an event log in Normal mode.
Figure 62. Event Log Example Displayed in Normal Mode
The events are displayed in a table. The columns in the table
shown in normal display mode are described below:
S (Severity)
The event’s severity. The severity codes and their corresponding
severity level and description are shown in Table 7.
Date/Time
The date and time the event occurred.
Event
This item contains two parts. The first part is the name of the
module within the AT-S63 management software that generated
the event. The second part is a description of the event.
Allied Telesyn AT-9400 Series - ATS63 V1.0.0
Production Switch
User: Manager 00:14:33 15-Mar-2004
Event Log
S Date Time Event
--------------------------------------------------------------------
I
02/24/04 12:31:02 ssh: SSH server disabled
I 02/24/04 12:31:02 garp: GARP initialized
I 02/24/04 12:31:02 ptrunk: Trunk initialization succeeded
Temporary (Memory) Log Events 1 - 10 of 340
P - Previous Page N - Next Page F - First Page L - Last Page
R - Return to Previous Menu
Enter your selection?
Table 7. Event Severity Levels
Severity
Code
Severity Level Description
E Error Switch operation is severely impaired.
W Warning An issue that may require network
manager attention.
I Information Useful information that can be ignored
during normal operation.
D Debug Messages intended for technical support
and software development.
