Chapter 30: TACACS+ and RADIUS Protocols
Section IV: Security 656
Displaying RADIUS Status and Settings
To display the RADIUS status and settings, perform the following
procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 51.
2. From the System Administration menu, type 6 to select
Authentication Configuration.
The Authentication Configuration menu is shown in Figure 205 on
page 648.
3. From the Authentication Configuration menu, type 4 to select
RADIUS Configuration.
The RADIUS Client Configuration menu is shown in Figure 208 on
page 654.
4. Type 6 to select Show Status.
The Show Status menu is shown in Figure 210.
Figure 210. Show Status Menu
The Show Status menu displays a table that contains the
following columns of information:
Server IP Address
IP address of the RADIUS server.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Show Status
Global Configuration
--------------------
Encryption Key : ATI
Server Timeout: 30 second(s)
Server IP Address Auth Port Encryption Key Auth Req Auth Resp
-------------------------------------------------------------
149.11.11.11
1812 WRRT 100 96
149.22.22.22 1812 LLST 4 4
149.22.22.22 1812 OORT 0 0
U - Update Display
R - Return to Previous Menu
Enter your selection?
