Chapter 17: MSTP
314 Section II: Advanced Features
Displaying the MSTP Port State
To display the MSTP port state, perform the following procedure:
1. From the Main Menu, type 3 to select Spanning Tree Configuration.
The Spanning Tree Configuration menu is shown in Figure 78 on
page 259.
2. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The MSTP menu is shown in Figure 95 on page 294.
3. From the MSTP menu, type P to select MSTP Port Parameters.
The MSTP Port Parameters menu is shown in Figure 99 on page
309.
4. From the MSTP Port Parameters menu, type 3 to select Display MSTP
Port State.
The following prompt is displayed:
Enter Spanning Tree (CIST/MSTI) ID to display port
state: [0 to 15} ->
5. Enter an MSTI ID.
The Display MSTP Port State menu is shown in Figure 101.
Figure 102. Display MSTP Port State Menu
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Display MSTP Port State
Spanning Tree Instance: 0 (CIST)
Port State
Role P2P Version Internal Port-Cost
--------------------------------------------------------------
1 Forwarding Root Yes MSTP 200000
2 Disabled
3 Discarding Alternate Yes MSTP 200000
4 Discarding Alternate Yes MSTP 200000
5 Disabled
6 Disabled
7 Forwarding Designated Yes MSTP 200000
8 Disabled
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
