Chapter 7: MAC Address Table
136 Section I: Basic Features
Adding Static Unicast and Multicast MAC Addresses
This section contains the procedure for adding static unicast and
multicast MAC addresses to the switch. You can assign up to 255 static
addresses per port on an AT-9400 Series switch.
To add a static MAC address, perform the following procedure:
1. From the Main Menu, type 4 to select MAC Address Tables.
The MAC Address Tables menu is shown in Figure 35 on page 132.
2. From the MAC Address Tables menu, type 2 to select MAC Addresses
Configuration.
The MAC Addresses Configuration menu is shown in Figure 39.
Figure 39. MAC Addresses Configuration Menu
3. From the MAC Addresses Configuration menu, type 1 to select Add
static MAC address.
The following prompt is displayed:
Please enter MAC address ->
4. Enter the static unicast or multicast MAC address in the following
format:
XXXXXX XXXXXX
After you have specified the MAC address, the following prompt
is displayed:
Enter port-list: [1 to 24] ->
5. Enter the number of the port on the switch where you want to assign
the static address. If you are adding a static unicast address, you can
specify only one port.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
MAC Addresses Configuration
1 - Add Static MAC Address
2 - Delete MAC Address
3 - Delete All Dynamic MAC Addresses
R - Return to Previous Menu
Enter your selection?
