Chapter 6: Port Parameters
124 Section I: Basic Features
The Display Port Statistics menu is shown in Figure 33.
Figure 33. Display Port Statistics Menu
The Display Port Statistics menu provides the following
information:
Bytes Received
Number of bytes received by the port.
Bytes Sent
Number of bytes transmitted from the port.
Frames Received
Number of frames received by the port.
Frames Sent
Number of frames transmitted from the port.
Broadcast Frames Received
Number of broadcast frames received by the port.
Broadcast Frames Sent
Number of broadcast frames transmitted from the port.
Multicast Frames Received
Number of multicast frames received by the port.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Oct-2004
Display Port Statistics
Port 6
Bytes Received .............. 983409801 Bytes Sent ............. 965734443
Frames Received ............. 815423 Frames Sent ............ 691396
Broadcast Frames Received.... 107774 Broadcast Frames Sent .. 1853
Multicast Frames Received ... 11429 Multicast Frames Sent .. 0
Frames 64 Bytes ............. 110509 Frames 65-127 Bytes .... 15192
Frames 128-255 Bytes......... 1928 Frames 256-511 Bytes ... 442
Frames 512-1023 Bytes ....... 157796 Frames >1024 Bytes ..... 1221024
CRC Error ................... 0 Jabber ................. 0
No. of Rx Errors ............ 0 No. of Tx Errors ....... 0
UnderSize Frames ............ 0 OverSize Frames ........ 0
Fragments ................... 0 Collision .............. 0
Frames 1519-1522 Bytes ...... 0 Dropped Frames ......... 0
U - Update Display
R - Return to Previous Menu
Enter your selection?
