Configuring VLANs
6
4. Provide the following information:
•
VLAN: Select the VLAN from the list.
•
VLAN Name: Enter the name of the VLAN. The name can contain 16 alphanumeric
characters and you can use blank spaces in the name if you enclose the name in double
quotes.
•
Router Interface: Select the Use check box for the routing interface to locally route the IP
packets from an IP subnet VLAN to the port-based VLAN on the same router. The range is
from 1 through 4095. The default value is 16.
5. Under Port Members, do the following tasks:
•
Tag: Select the check box only if a port connecting the Brocade Virtual ADXs is a member
of one or more port-based VLAN.
•
Select the ports from the Available Ports list and click Add to add the ports to the Selected
Ports list.
NOTE
To remove a port from the Selected Ports list, click Remove. To remove all the ports from the
selected list, click Remove All.
6. Click Apply to save your entries.
Click Reset to revert the configuration to the previous configured values.
To modify the configured VLAN information, in the Summary table, select an entry and click
Edit or double-click the entry. You can also delete a configuration by clicking Delete.
For more information on the VLAN configuration, refer to the Brocade Virtual ADX Switch and
Router Guide.
